Uniform Resource Locator - URL

A URL (Uniform Resource Locator) is a string used to uniquely identify and locate the address of a resource on the Internet or another network. A URL typically consists of several parts that specify various information about the resource:

  1. Protocol: The protocol specifies how the resource should be accessed or transferred. Common protocols include HTTP (Hypertext Transfer Protocol), HTTPS (HTTP Secure), FTP (File Transfer Protocol), and FTPS (FTP Secure).

  2. Hostname: The hostname identifies the server where the resource is hosted. This can be a domain like "example.com" or an IP address indicating the exact location of the server.

  3. Port (optional): The port is a numerical address on the server that allows access to specific services. Default ports are often used implicitly (e.g., port 80 for HTTP), but custom ports can also be specified for special services.

  4. Path: The path specifies the location of the resource on the server. It can refer to a specific directory or file.

  5. Query string (optional): The query string is used to pass additional parameters to the server that can be used to identify or customize the requested resource. The query string starts with a question mark and usually contains a series of key-value pairs separated by the ampersand (&).

Together, these parts of a URL form the complete address of a resource on the Internet or another network. URLs are used in web browsers, hyperlinks, APIs, and other internet applications to access and identify resources.




Firewall

A firewall is a network security device or software that monitors and controls incoming and outgoing network traffic based on predetermined security rules. It acts as a barrier between a trusted internal network and untrusted external networks, such as the internet, to prevent unauthorized access to or from the internal network.

Firewalls can be implemented in various forms:

  1. Network Firewall: This type of firewall is typically deployed at the perimeter of a network, such as between an organization's internal network and the internet. It examines packets of data as they pass through, filtering them based on predefined rules to allow or block traffic.

  2. Host-Based Firewall: Host-based firewalls are installed on individual computers or devices to control traffic at the device level. They provide an additional layer of defense by filtering traffic based on specific rules configured for that host.

Firewalls operate based on different filtering methods:

  • Packet Filtering: Packet-filtering firewalls examine packets of data as they pass through the network based on criteria such as source and destination IP addresses, port numbers, and protocols. They make decisions to allow or block packets based on predefined rules.

  • Stateful Inspection: Stateful inspection firewalls keep track of the state of active connections and use this information to make decisions about whether to allow or block traffic. They maintain a record of the state of connections, such as TCP handshakes, and only allow traffic that corresponds to legitimate, established connections.

  • Proxy Firewalls: Proxy firewalls act as intermediaries between clients and servers, intercepting and inspecting traffic before forwarding it to its destination. They can provide additional security by hiding the internal network's IP addresses and applying advanced security measures such as content filtering and application-layer inspection.

Firewalls are a fundamental component of network security and help protect against unauthorized access, data breaches, malware infections, and other cyber threats by enforcing access control policies and filtering potentially harmful traffic.




Port

A port is a logical communication endpoint that allows various applications on a computer to send and receive data. In networking technology, a port refers to a number that is assigned to a specific application or service on a computer, used to control traffic to that application or service.

Ports are typically represented by a 16-bit number and can range in value from 0 to 65535. The first 1024 ports are known as well-known ports and are reserved for specific services. For example, port 80 is commonly reserved for HTTP (Hypertext Transfer Protocol) used for web traffic, while port 443 is typically reserved for HTTPS (HTTP Secure) used for encrypted web traffic.

Ports are often used in conjunction with the Transmission Control Protocol (TCP) and the User Datagram Protocol (UDP), both of which are protocols in the Internet Protocol suite (TCP/IP). TCP is a connection-oriented protocol suite, while UDP is a connectionless protocol suite. Both protocols use ports to facilitate data communication between different applications.
